Ultrasound

A flat array of a hundred and twenty-eight elements diced at about three tenths of a millimetre, running at ten megahertz. It does not steer. It fires a group of adjacent elements straight down, forms one line, then slides the active group one element along and does it again, which is why the image is a rectangle exactly as wide as the probe.

Also called: Ultrasound Machine, Ultrasound Scanner, Sonography. Arabic: جهاز الموجات فوق الصوتية. Device Lab 36 of 69 in BMEssentia Medical City, 2 configurations.

Overview: the configurations

How it works: the main parts

What each part does, from the Ultrasound lessons in the 3D Device Lab.

Mains inlet, isolation and protective earth

An inlet, a fuse and an earth stud on the back of the tower, and behind them something most equipment in the building does not have: a transformer whose only job is to make sure the patient is not connected to the mains by any route at all.

Transmit pulser

A bank of high-voltage switches, one per channel, that slam a hundred volts or so across a piezoelectric element for a fraction of a microsecond and then stop. It is the loudest thing in the machine electrically and it does nothing at all for the other ninety-nine per cent of the time.

Transmit and receive beamformer

The board with the largest chip on it and the most channels running to it. Nothing about it moves and nothing about it is acoustic, and it is where the beam actually comes from.

Preamplifier and time-gain compensation

A row of small amplifiers immediately behind the connector, one per channel, and a gain that climbs while it is listening. It is the first thing the echo meets and the last chance to amplify it before noise is added.

Digitiser

A row of converters turning each channel into numbers, tens of millions of times a second. Everything before it is analogue and fragile; everything after it is arithmetic and can be copied without loss.

Envelope detection, compression and scan conversion

The stage that turns a line of radiofrequency signal into a line of grey pixels, and then turns a fan of such lines into a rectangle a screen can display. Three operations, each of which throws information away on purpose.

Upper display

The large screen on the articulated arm, angled towards whoever is reading rather than whoever is scanning. In a room with the lights down it is the brightest object in the space.

Touchscreen control display

The smaller angled screen above the keys, raked back so a seated operator can reach it without looking away from the patient for long. Its content changes with the mode, which is the whole reason it exists.

Explore it in the Device Lab

• The account everything is bought from: Change the frequency and watch four numbers at once: axial resolution, lateral resolution, penetration and the mechanical index.
• The number that decides whether a probe can steer: Set the steering angle to zero and step it outwards, watching for the angle at which a grating lobe appears. Do it on both probes.
• One number that is three things: Change the depth and watch the pulse repetition frequency, the frame rate and the Nyquist velocity all move together.
• Why bone is white and air is a wall: Compute the reflection coefficient at three boundaries: tissue against fat, tissue against bone and tissue against air.
• What 1540 metres per second costs: Set a speed-of-sound error and watch the reported depth against the real one.

Common faults and what to check

Most reported device problems (FDA MAUDE)

Raw counts of adverse event reports for this device type (FDA product code IYO, ITX), all years. Not adjusted for the number of units in use, so they show what gets reported, not failure rates. Report text is never copied.

Planned maintenance checks

From the BMEssentia procedure library: every 12 months, about 60 minutes, electrical class I, applied part type BF.

Test instruments: Tissue-mimicking QA phantom; Electrical safety analyser; Probe leakage tester (for endocavity and TOE probes).
